43'' windows capacitive LCD touchscreen table multi touch table
| LCD Screen |
Resolution |
3840*2160 |
Screen Ratio |
16:9 |
| Dynamic Contrast |
≥5000:1 |
Viewing Angle |
≥178° |
| Brightness |
500cd/m2 |
Life Time |
100000h |
| Brand New A+degree 4K Screen Full-screen Display without black border, no blind spot |
| Touch Screen |
Resolution |
4096*4096 |
Touch Points |
10 points |
| Minimum Touch Item |
≥1mm |
Response Time |
<5ms |
| Surface Hardness |
Mohs 7degree |
Cursor Speed |
≥180/ms |
| Transmittance |
≥98% |
Durability |
Unlimited |
| ≤5mm Explosion Protection Toughened Glass for The Writing Surface, Scratch-resistant,anticollison.anti-glare |
| PC Configutation |
Main Board CPU |
Intel J1900 4core/I3/I5 Processor |
| Hard Drive |
120G SSD |
RAM |
4G/DDR3/I333 |
| USB Connectors |
6pcs |
Built-in wifi |
standard IEEE 802.11n |
| Interface |
HDMI 2,VGA 1,USD 2,AV 2,RPbPr 1 |
| Speaker |
10W*2 |
| Integrated All-in-one Design |
| Accessories |
AC Power Cable |
| Operating System |
Win 7/Win 8/ Win10 |
| Description |
10-points touch,Explosion protection and anti-glare for the LCD Screen |
Our Products(LCD touchscreen table)
A multi-purpose Usage(For home,business,entertainment...)
1.Touchscreen table can be used for home table function,game entertainment,drawing or playing chess...
2.During business occasion,it makes your negociation more relaxed,while having a cup of tea around the table.
3.KTV table,all in one table,you don’t need to equip with another song-ordering sets.
High-end table reduce your cost as well.
Seamless Capacitive Screen
(Smooth touch operation even an articles or water drop on the surface)
Flat mirror seamless surface ,easy for cleaning,simple but elegant appearance The operating
sensitivity is smooth even the articles or water drop on the surface.
Really nice touchscreen,without any freeze or pauze,smooth touch sensitivity.
Especially for playing game.
Capacitive touch screen is different from the Infrared screen,the infrared table is uneasy for cleaning
because of the groove around,the sensitivity will be affected by light and radiation as well.
10-points Touch(Multi-character operate)
Using mobile phone touch screen technology,high sensitivity,precise touch.
quick response,it can be operated by 10 people at the same time.
Operating Gesture(Multi-operating gesture)
It supports all kinds of operating gesture,single or two hands will be ok.Zoom in/ Zoom out,minify/magnify,rotate.
Simple operation,all is under your control.
Hi-fi Audio(360° suroud effect)
Clear audio,smooth and steady sound,clear conversation even in a noisy environment.
WINDOWS System(work+leisure)
It shares the same function of the computer,it can be connected with the USD ,printer, wifi,wired Internet externally.
Printing file,going through the web page,watching video, Playing game...
Customized Shape and Style(different shape as your requirement)
1,We can customized different size /style/shape as your requirement.The shape below, for example,
the hollow area can hold a water-drinking barrel,which is convenient for drinking tea on the business occasion.
All kinds of the style will be ok.
Products Size
Full HD IPS screen
Full HD IPS screen, 1920*1080 resolution. Strong ability of color restoration, high saturation, aspect ratio 16:9. Intelligent backlight control.
Ultimate sense of touch control
Adopt high sensitivity 10-point capacitive touch panel, coordination with high frequency self-touch chip, G+G lamination technology. High hardness screen, scratch resistant and wear-resistant, high transmittance, sensitive touch, quick response
Android 4.4 OS
Quad-core/WiFi/wired and plug in 3G/4G network/10-point capacitive touch panel/split screen multi task windows/hide the system bar/timing power-off power-on/support download Android application
VESA function
HD advertising displayer, widely used. Use for bank, market, company, hospital, hotel, campus, airport, cinema and media company.
Spectification
| LCD screen |
23.6" or 32 inch TFT 1920*1080 tv digital signage |
| Type of Touch Panel |
pacitive touch screen,Support 10-point |
| OS |
Android 4.2 |
| CPU |
RK3188,Quad Core ARM Cortex A9(@)1.6GHz And Quad Mali 400@533Mhz (Mali400MP4) |
| RAM |
DDR3 2GB |
| Nand Flash |
8GB |
| Camera |
Front 0.3MP (2.0MP optional) |
| Wi-Fi |
802.11b/g/n |
| Bluetooth |
Bluetooth 3.0 Module |
| G-Sensor |
Yes |
| Speaker |
2W x 2 speaker x 2 |
| Audio format |
MP3,WMA,WAV,OGG,AAC,FLAC,3GP |
| Video format |
MPEG2,MPEG4,AVI,WMV,MKV,MOV,RM,RMVB |
| Photo |
JPG,BMP,PNG |
| Micro USB |
for OTG |
| USB port |
HOST 2.0 (5V 1A)*3 |
| DC port |
Yes |
| Earphone |
20mW (@) 16 Ohms ,Stereo,Diameter 3.5mm earphone jack |
| MicroSD slot |
Yes |
| Button |
Power |
| Housing case |
Metal (ABS+PC) |
 |
